Main Hardware Characteristics
| Display Type | 90×90 pixels backlit LCD |
| Autonomy Learn more | >20 hours at a rate of one position per second |
| Size | 87x58x22.5 mm (Length x Width x Thickness) |
| Weight | 93g |
| GPS | 72 GPS/GLONASS channels |
| Native USB Connection | Allows connection to a PC to update the firmware |
| Battery Charging | From a power adapter or standard USB port |
| GSM |
|
| Pressure Sensor | Allows to measure barometric data |
| Bluetooth | BLE Bluetooth 5.0 and Bluetooth mesh |
| Flarm/ADSL-M | Flarm and ADSL-M Ready |
Variometer/Altimeter Features (optional)
- Buzzer/near thermal sound
- Ultra sensitive Variometer with 10 readings per second and 10 cm resolution
- Configurable vario digital filter and integration values
- Fully configurable Vario Sound (frequency, increments, frequency/vertical speed relation,….)
- Adjustable Sound Levels
- Automatic mute, keeps vario silent until takeoff
- Altitude adjustment using QNH
- Automatic altitude adjustment from GPS
Navigation Features (optional)
- Goto waypoint
- Multiple waypoint route
- Wind Speed and Direction (GPS based calculations)
Live Tracking
- Flight data can be efficiently uploaded to various repositories, such as the Leonardo XC server, XContest, and DHV, utilizing the GSM network.
- Automatic almost real time flight data sending to a remote live tracking server through GSM network. (compatible with several servers like Flymaster, LiveTrack24, DHV, etc)
- On demand sending of predefined messages to a server (eg. Need Assistance, Need Retrieval, etc)
- Effortlessly receive data from a remote server, including alarm messages, task definitions, and more, through automated processes.
- Optimized LTE-M/GPRS data usage is minimal, with an average requirement of only 25KB per flight/hour, assuming uninterrupted communication.
Interfacing
Compatible with MacOS (10.13 and higher), Windows (7/8/10/11), IOS and Android
⚠️ Important Notice About the LiveTracking Feature
The LiveTracking functionality available on our devices requires the activation of a continuous connectivity service, which involves a monthly fee.
However, this service can be suspended during months when LiveTracking is not in use.
To enable LiveTracking, the following minimum monthly charges apply:
- Tracker 4G and LiveONE: service available from €3.99 / month
- Live C and Live DS: service available from €2.99 / month
Without an active subscription, real-time tracking will not be available.
Disclaimer
The Flymaster Live Tracking system operates exclusively through terrestrial LTE-M and 2G communication networks.
Consequently, the availability and reliability of live tracking services are entirely dependent on the coverage and performance of these networks.
Devices equipped with Enhanced Live Tracking (i.e., incorporating the Flarm module) may, however, provide improved tracking performance in certain situations where standard LTE-M and 2G connectivity is limited or unavailable.
The additional transmission capabilities of the Flarm module can enhance visibility and data exchange within compatible networks and infrastructures.
Nevertheless, communication and tracking cannot be guaranteed in areas lacking terrestrial network coverage or adequate signal propagation.
Users are therefore advised that instruments relying on terrestrial communication networks must not be regarded as emergency or safety-of-life devices, nor as providing assured connectivity or location transmission under all circumstances.
Flymaster shall not be held liable for any failure of communication, tracking, or data transmission arising from network unavailability or related technical limitations.
